Model |
Nominal power capacity |
Rated voltage(KV) |
Reactive power |
Current Maximum |
Dimension(mm) |
Temperature coefficient |
|||||
|
(PF) |
DC |
HF(RMS) |
(KVA) |
(A) |
D |
H |
h1 |
h2 |
Copper Nut |
(PPM/℃ ) |
|
|
CCGS-0 |
500 |
20 |
15 |
1000 |
150 |
095 |
162 |
18 |
55 |
M8 |
-750 |
|
1000 |
|||||||||||
|
2000 |
14 |
12 |
1500 |
||||||||
|
2500 |
|||||||||||
|
5000 |
12 |
10 |
1275 |
220 |
110 |
||||||
|
CCGS-1 |
1000 |
20 |
15 |
2000 |
200 |
110 |
255 |
20 |
105 |
||
|
2000 |
|||||||||||
|
3000 |
|||||||||||
|
CCGS-2 |
2000 |
20 |
15 |
2000 |
250 |
135 |
242 |
22 |
108 |
||
|
2500 |
25 |
20 |
2500 |
||||||||
|
3000 |
20 |
15 |
2000 |
||||||||
|
4000 |
16 |
12 |
2500 |
218 |
|||||||
|
5000 |
2830 |
250 |
128 |
||||||||
|
5000 |
20 |
15 |
3000 |
285 |
134 |
||||||
|
6000 |
16 |
12 |
2830 |
272 |
134 |
||||||
|
6000 |
20 |
15 |
3000 |
320 |
170 |
||||||
|
CCGS-3 |
4000 |
24 |
20 |
3000 |
250 |
142 |
285 |
25 |
134 |
||
|
5000 |
314 |
||||||||||
|
6000 |
20 |
15 |
320 |
||||||||
|
CCGS-4 |
5000 |
30 |
25 |
3500 |
300 |
158 |
340 |
30 |
170 |
M10 |
|
High power ceramic
capacitor technical parameters:
1. Typical dissipation factor: ≤0.0008；
2. Volume resistivity: ≥10000MΩ；
3. Permissible variation of rated capacitance: K（+/-10%）；
4. Temperature range: -40/+85；
5. Rated temperature: +85℃；
6. Maximum relative humidity: 75%;
7. Test voltage: 2 times of rated voltage if the rated voltage≤15KV or 1.5
times of rated voltage if the rated voltage>15KV.
